POWERCOM BATTERY PACK 2200-AP

GENERAL INFORMATION Model Type KING PRO Model Name KIN-2200AP Power Rating 2200VA/1320W

AC INPUT AC Input Capacity on Battery 2200VA AC Input Voltage 100V/110V/120 +/- 25%; 220V/230V/240V +/-25% AC Input Frequency 50 or 60 Hz+/-10% (auto sensing)

OUTPUT Output Voltage On Battery 100V/110/120V +/- 5%; 220V/230V/240V +/- 5%

AC OUTPUT AC Output Voltage Simulated sine ware AC Output Frequency 50 or 60 Hz +/- 0.5% AC Output Voltage Regulation AVR automatically increase output voltage 15% above input voltage if -9% to -25% of nominal. AVR decrease output voltage 13% below input voltage if +9% to +25% of nominal AC Output Transfer 2/4 milliseconds, including detection time

PROTECTION Protection Spike 320 Joules, 2ms Protection EMI/RFI 10dB at 0.15 MHz, 50 dB at 30 MHz Protection Overload UPS automatic shutdown if overload exceeds 110% nominal at 60 sec and 130% at 3 sec Protection Unit Fuse for overload & short circuit protection Protection 10 BaseT Network (UTP, RJ-45) compatible jacks Protection Short Protection UPS output cut off immediately or input fuse protection

BATTERY Battery Type Sealed, Maintenance-free lead acid, with 3 – 6 years typical lifetime Battery Typical 4 hours (to 90% of full capacity) Battery Protection Automatic self-test & discharge protection, replace battery indicator

BACKUP TIME Battery Backup Time Full Load 7 minutes Battery Backup Time Half Load 15 minutes

PHYSICAL Physical Weight kgs Tower 30 Physical Weight lbs Tower 66 Physical Dimension mm Tower 170x448x214 Physical Dimension inch Tower 6.7×17.6×8.4

INDICATOR LED LED

ALARM Alarm Battery Backup Slow beeping sound (about 0.47 Hz) Alarm Battery Low Rapid beeping sound (about 1.82Hz) Alarm Overload Continue beeping sound

INTERFACE Interface RS-232 Bi-directional communication port

ENVIRONMENT Environment Ambient 3,500 meters max. elevation, 0-95% humidity non-condensing, 0-40 deg c Environment Audible <40dBA (1 meter from surface) ShowOrder 20
